Products / SES System
One system. Four components. Complete field power independence.
The SES System integrates a sun-tracking concentrator solar collector, modular battery storage, an intelligent docking system, and a field-grade power inverter into a single deployable platform. Skid-mounted or trailer-based. Operational in under 30 minutes.
System Architecture
Four integrated components. One deployable unit.
01
SunDog
CPV Solar Collector
Concentrating photovoltaic collector with full-arc sun-tracking. Harvests solar energy via Fresnel lens optics and delivers consistent output from morning to evening.
02
Docking System
Charging & Control
Plug-and-play battery connection that manages charging, battery chemistry detection, and safety interlocks automatically. No setup required.
03
BESSe Modules
Energy Storage
1–10 human-portable battery modules store solar-charged energy for on-demand dispatch. 2400Wh (23 kg) or 1200Wh (12 kg) units. Same docking interface at every scale.
04
System Inverter
Power Output
Delivers 120V/60Hz, 240V/50Hz, and split-phase AC output. Pure sine wave. Sized for industrial loads including motor starting.
Specifications
Operating temperature
-40°C to +50°C
Battery self-heating below -20°C
Platform footprint
96″ × 48″
Skid, pallet (48″×40″), or trailer
Battery modules
1–10 per platform
2400Wh (23 kg) or 1200Wh (12 kg) units
AC output
120V/60Hz · 240V/50Hz · Split-phase
Pure sine wave
DC output
USB-C PD 100W · 12V DC
Per BESSe module
Setup time
Under 30 minutes (target)
Full electrical, mechanical, and thermal specifications — including interface drawings, efficiency curves, and integration data — are available under NDA for qualified partners.
Deployment Configurations
Extended Skid
96″ × 48″
Primary field deployment configuration. Supports one SunDog collector and up to 10 BESSe modules.
Standard Pallet
48″ × 40″
Transport and contained site configuration. Optimised for helicopter or vehicle delivery.
Trailer
Mobile
Relocatable between sites. Full SES System capability with road-mobile flexibility.
Economics
The SES System pays for itself by eliminating diesel operating cost.
At remote industrial and defense sites, diesel fuel, transportation, and generator maintenance represent a predictable, recurring operating expense. The SES System targets a payback period measured in months — not years — in high-consumption environments.
Detailed cost analysis — including fuel cost modelling for your site type, acquisition cost, and ROI timeline — is available as part of our technical specifications package.
Request Economics AnalysisBuilt For
One platform. Designed for the environments that matter.
Portable Scale
The same system. At personal scale.
Sun Cradle is one SunDog hex and one BESSe module — the complete SES System architecture in a two-person carry package. Same plug-and-play docking interface. Same technology. Add a second hex, a second battery, and scale to a full platform. Every component is interchangeable.
Learn about Sun Cradle →Accepting qualified pilot partners for 2026 deployments.
Technical specifications — including electrical interface, thermal envelope, mechanical integration, and full economics analysis — are available under NDA for qualified partners. Request your package to begin the process.
